Product Introduction
1. Application
Confectionery/peanuts/snack/chips/nuts/jelly/flakes/cookies/bakery/coffee beans
/pet foods/dry granule or small hardwares
2. Main Features:
◆ Mold hoppers can be change with each other.
◆ High speed stagger dump function.
◆ User-friendly help menu in touch screen contributes to easy operation
◆ 100 programs for multiple tasks.
◆ Program recovery function can reduce operation failure.
◆ High precision digital load cell.
◆ Linear amplitude can be adjusted independently.
◆ No products auto pause function can improve weighing stability and accuracy.
◆ Modular control system, AD cards no need Number, can be interchangeable.
◆ New actuaor design reduces the mechanical vibration and improves the accuracy of load cell.
◆ Each drive board is independent, can be changed freely, even in different weighers.
◆ Friendly HMI, similar with mobile phone operation icons, make operation more easily and simple.
◆ Weighers with strong self-checking function, can realize the closed loop testing, real-time detect abnormalities in each node, and real-time display in human-machine interface.
◆ The software versatility, strong compatibility, different weighers using the same control
system.
Specification
3. Technical Specification
|
Model |
XR-1A14(16) |
|
Single Weighing range |
10-2000 g |
|
Avg. Accuracy |
0.5~2 g |
|
Production wpm |
120 wpm |
|
Control panel |
7 inch color touch screen |
|
Hoppers Volume |
1.6L (single door), plain plate/dimple plate |
|
Construction material |
304 Stainless Steel |
|
Driving system |
Step Motor |
|
Control system |
Modular control system |
|
Power requirement |
AC 220V/110V ±10%50Hz（60Hz）1400W |
|
Options |
Dimple plate/timing hopper/printer/rotary top cone/multi-mouth top cone/reject device |
|
Packaging dimension (mm) |
L1720*W1100*H1130mm |
|
Gross weight |
500kg |
