Product Introduction
1. XR-900 X-ray detection machine runs at a standard speed of 12m/min (600 bag/min); with the speed adjustable
2. X-ray tube made in the US with the voltage and current adjustable
3. Sensor: multi-mode 0.4×2.0(mm) CMOS sensor from Japan
4. High-speed embedded DSP system is adopted for the baggage screening machine
5. Display: 22cun full screen display; high-resolution and easily-recognized image
6. The high-performance X-ray image processing system, FPGA chip with high-speed algorithm, high-resolution large-screen display, extended functionality, accompanied with user-friendly human-machine interface provides a high inspection accuracy
2. X-ray tube made in the US with the voltage and current adjustable
3. Sensor: multi-mode 0.4×2.0(mm) CMOS sensor from Japan
4. High-speed embedded DSP system is adopted for the baggage screening machine
5. Display: 22cun full screen display; high-resolution and easily-recognized image
6. The high-performance X-ray image processing system, FPGA chip with high-speed algorithm, high-resolution large-screen display, extended functionality, accompanied with user-friendly human-machine interface provides a high inspection accuracy
7. The X-ray equipment is of high testing accuracy, and can clearly show small foreign bodies, and 0.7mm-diameter metal balls
Specification
| Passageway size | 400-650mm (width), 200-550mm (height) |
| Machine dimension | 2500 × 880 × 1400mm |
| Conveyor height | 600-800mm |
| Rated conveyor load | 70 kg |
| X-ray leakage | 0.502 μ Gy/h; in line with national health and safety requirements on radiation devices |
| Voltage | AC220V, 50 ± 3Hz |
| X-ray tube voltage | 100~160 kV (adjustable) |
| Power | 0.5KW/h |
| Working environment | temperature: 0℃~60℃; humidity: 20%~90% (non-condensable gas) |
| Noise | ≤ 57dB |
