Product Introduction
The Juzheng XR-720C Industrial Conveyor Belt Needle Detector is mainly used for detecting ferrous metal that load or drop in raw materials and products in the field of toy, costume, shoemaking, chemical industry, leather, knitting etc.
Functions:
A.high sensitivity and strong interference immunity.
B.light structure and move conveniently.
C.various of specifications of inspection window which can be chosen at will according to customers’ needs.
D.quick conveying speed,applicable to pipeline operation.
E.matches the pipeline operation or automatic control device.
Specification
MODEL | XR-720C | ||||
Detection approach | electromagnetic induction, digital circuit processing | ||||
Sensitivity | ≥FeΦ 0.8 | ≥FeΦ0.8 | ≥FeΦ1.0 | ≥FeΦ1.2 | ≥FeΦ1.5 |
Detection height | 100mm | 120mm | 150mm | 200mm | 250mm |
Detection width | 600mm (customizable) | ||||
Detection adjustment | 1-12 level | ||||
Alerting method | audible alert, shutdown, go backwards, and then restart | ||||
Power supply | Ac220V 50-60Hz | ||||
Power | 140W | ||||
Machine dimension | L1820mm×W1050mm×H900mm | ||||
Weight | 280KG |
